Max Energy [kWh]

80

Energy, 90% DoD [kWh] 1

72

Energy, 80% DoD [kWh] 1

64

Nominal Voltage [V] 2

410

Max/Min Operating Voltage [V]

454/365

Max/Cont Discharge Current [A]

250/200

Max/Cont Discharge Power [kW]

102/80

Max and Cont Charge Current [A]

200

Weight [kg]

637

Dimensions on or against wall excluding protuberances such as glands and breaker handle -Height x Width x Depth [mm]

1451x668x566

DC Connection – Fly Leads, [no. per electrode] 3

1 x 50mm2

External Interfacing

CAN Bus

Enclosure

Aluminium – powder coated white, IP54 enclosure rating, Home – wall or floor mount, Business – floor mount

Protection

Shunt Trip Circuit Breaker sized to suit max current, can be tripped by BMS if critical fault incl. overcurrent,

cell under and over voltage, temperature, weak cell detection, minimum SOC control, manual reset

Human Interface

State of Charge Display (0 to 100%), Error light, Error Reset Button, USB Plug for Programming

Service Life 4

10 year (or 4000 cycles) warranty for 80% average DoD, 13-15 yrs (>5 500 cycles) expected life at 70% DoD, 15-20 years at 50% DoD (>7 000 cycles)
